65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket

65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket

  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
  • 65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket
Product Details:
Place of Origin: Guangdong, China
Brand Name: Boente
Certification: ce
Contact Now
Detailed Product Description
Private Mold: Yes Type: Ceiling TV Mount
Max Vesa: 600x400 Material: Cold Rolled Steel
Maximum Tilt Angle: 105 Maximum Compatible Size: 55"
Minimum Compatible Size: 32" Suitable TV Size: 32~65 Inch Plasma TV
Rotate Angle: 0-105 Degree Control System: Remote Control/ Wired Switch
Voltage: 110-240AC Warranty: 1 Years

Products Description


TCL-3 is a LCD TV hidden hanger specially developed for conference engineering, home furnishings, and hotel room applications. It uses professional worm motors from top domestic brands and independently developed digital control circuit boards to ensure reliable and stable operation of the product.
Product name
TV ceiling flipper
PRODUCT MODEL
TCL-3
Flip angle
0-110 ° (adjustable up to 116 °)
Wiring method
Adopting tank chain wiring and built-in wires
Electrical machinery
Communication worm motor
Bear a heavy burden
Net weight of TV set less than 45KG (excluding bracket)
Flip positioning method
Mechanical positioning (with dual protection)
Colour
High gloss white (other colors can be customized)
Elevating height
85 cm (can be equipped with secondary lifting, with electronic limit for up and down lifting)
Remote control distance
50 meters (open space)
Body thickness
210mm (customizable minimum 170mm)
Suitable for installing television
Within 65 inches
Control interface
Wireless remote control, buttons RS232
INPUT VOLTAGE
220V~50/60Hz (customizable voltage 110V)
Power consumption
≤ 100W (standby ≤ 0.5W)
Weight
158kg (net weight)
Installation method
Ceiling hoisting
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 0
Product Features
1. Framework structure, simple and easy to install 2. Adopting high-quality AC deceleration, long service life, and good stability 3. Built in integrated control board with high reliability 4. The flip angle can be adjusted, resulting in a more perfect sound performance.
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 2

Adopting an electric flip design, the LCD screen/TV is perfectly hidden in the ceiling, and the lifting process is quiet and smooth.
The descending height depends on the size of the TV (supporting TVs up to 65 inches)
Product Details
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 4
Close
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 6
Open
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 8
Telescoping
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 10
Lower limit
Project Case
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 12
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 14
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 16
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 18
55 inch size
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 20
65 inch size
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 22
Other Hot Sale Production
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 24
Company Profile
65-Inch Motorized TV Lift Stand with Remote Control Ceiling Flip Down TV Bracket 26
Boente is an integrative high-tech enterprise which collects research, development, production, sale and service. Our head office was established in Hong Kong for our import and export business. Since 2009, primary cognizance product research, production and sale department Boente branch (Guangzhou Boente Technology Co.,Ltd) was settled in Guangzhou. We focus our full energy on audio video system equipment, specializing in the manufacture of LCD monitor lift, desktop socket, projector mount, projector screen, electric desktop flip up socket, pop up socket, flip up LCD monitor, plasma TV lift, media table socket, cable cubby, microphone lift and other related products. Also customization for audio video solution. Boente major to develop in supply paperless office system or conference system. Product quality approved by CE, ROSH, SASO, FCC and UL certification. As excellent and steady quality, professional technical support and impeccable after-sale service, our products are popular in Chinese local and global market, especially in Middle East, Europe and Southeast Asia market, like Saudi Arabia, UAE, Poland, Russian, Iran, Italy, India, Jordan, Kuwait...
